Product Summary

The IPW90R120C3 is a CoolMOS Power Transistor.

Parametrics

IPW90R120C3 absolute maximum ratings: (1)Continuous drain current: 36 A at TC=25 ℃, 23 A at TC=100 ℃; (2)Pulsed drain current: 96 A at TC=25 ℃; (3)Avalanche energy, single pulse: 1940 mJ at ID=8.8 A, V DD=50 V 1940 mJ; (4)Avalanche energy, repetitive t AR: 2.9 mJ at ID=8.8 A, V DD=50 V; (5)Avalanche current, repetitive t AR: 8.8 A; (6)Power dissipation: 417 W at TC=25 ℃; (7)Operating and storage temperature: -55 to 150 ℃.

Features

IPW90R120C3 features: (1)Lowest figure-of-merit RON x Qg; (2)Extreme dv/dt rated; (3)High peak current capability; (4)Qualified according to JEDEC1) for target applications; (5)Pb-free lead plating; RoHS compliant; (6)Worldwide best R DS,on in TO247; (7)Ultra low gate charge.

Diagrams

IPW90R120C3 diagram

Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
IPW90R120C3
IPW90R120C3

Infineon Technologies

MOSFET COOL MOS

Data Sheet

0-142: $6.74
142-250: $6.14
250-500: $5.74
500-1000: $5.27
