Product Summary

The IRFB4310 is a HEXFET Power MOSFET. The applications of the IRFB4310 include High Efficiency Synchronous Rectification in SMPS, Uninterruptible Power Supply, High Speed Power Switching, Hard Switched and High Frequency Circuits.

Parametrics

IRFB4310 absolute maximum ratings: (1)Continuous Drain Current, VGS @ 10V A: 140 A; (2)ID @ TC = 100℃ Continuous Drain Current, VGS @ 10V: 97 A; (3)IDM Pulsed Drain Current: 550 A; (4)PD @TC = 25℃ Maximum Power Dissipation: 330 W; (5)Linear Derating Factor: 2.2 W/℃; (6)Gate-to-Source Voltage: ±20 V; (7)Peak Diode Recovery: 14 V/ns; (8)Operating Junction and Storage Temperature Range: -55 to +175 ℃.

Features

IRFB4310 features: (1)Worldwide Best RDS(on) in TO-220; (2)Improved Gate, Avalanche and Dynamic dV/dt Ruggedness; (3)Fully Characterized Capacitance and Avalanche SOA; (4)Enhanced body diode dV/dt and dI/dt Capabilit.

Diagrams

IRFB4310 diagram

Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
IRFB4310
IRFB4310

International Rectifier

MOSFET N-CH 100V 140A TO-220AB

Data Sheet

1-150: $2.28
IRFB4310GPBF
IRFB4310GPBF

International Rectifier

MOSFET MOSFT 100V 140A 7mOhm 170nC

Data Sheet

0-1: $3.52
1-25: $2.41
25-100: $1.79
100-250: $1.71
IRFB4310ZPBF
IRFB4310ZPBF

International Rectifier

MOSFET MOSFT 100V 127A 6mOhm 120nC Qg

Data Sheet

0-1: $2.28
1-25: $1.55
25-100: $1.16
100-250: $1.11
IRFB4310ZGPBF
IRFB4310ZGPBF

International Rectifier

MOSFET MOSFT 100V 127A 6mOhm 120nC

Data Sheet

0-1: $2.39
1-25: $1.63
25-100: $1.22
100-250: $1.16
IRFB4310PBF
IRFB4310PBF

International Rectifier

MOSFET MOSFT 100V 140A 7mOhm 170nC

Data Sheet

0-1: $3.62
1-25: $2.47
25-100: $1.84
100-250: $1.76
IRFB4310Z
IRFB4310Z

Other


Data Sheet

Negotiable
